General information
|
Job Number |
|
0210-63 |
|
||
|
|
|
|
|||
|
Equipment type |
|
VCR |
|||
|
|
|
|
|||
|
Maker + Model # |
|
Panasonic L15 |
|||
|
|
|
|
|||
|
Made in |
|
|
|
||
|
|
|
|
|||
|
|
|
|
|||
|
|
|
|
|||
|
Date in |
|
11-Oct |
2002 |
||
|
Date of repair |
|
|
2002 |
||
|
Date out |
|
|
2002 |
||
|
|
|
|
|||
|
Comments |
|
VCR model very similar to the J30, and also have a
similar power supply problem |
|||
Symptoms observed
BAD |
1 |
The power supply fails when clicking Rew or
Ff or Play, and the VCR resets to Stop Mode. |
|
|
|
|
|
|
|
|
GOOD |
1 |
Good mechanical function
and tape drive. |
|
|
|
|
Repair notes
Full repair description and observations |
|
|
|
|
|
1 |
Replaced all Capacitors in primary side of
Power supply, including a ceramic capacitor – C37. I also changed the 2
diodes in the primary (VSD0002 and AP011c) and some large capacitors in the
secondary. |
|
Repair summary |
Some components in the primary were changed, esp
capacitors. |
Precautions, fouls and advises |
|
|
|
|
|
1 |
|
Other measurements and technical comments
|
1 |
n/a |
