General information
|
Job Number |
|
0209-64 |
|
||
|
|
|
|
|||
|
Equipment type |
|
VCR |
|||
|
|
|
|
|||
|
Maker + Model # |
|
Grundig VS 400 VPS |
|||
|
|
|
|
|||
|
Made in |
|
|
|
||
|
|
|
|
|||
|
Client Info |
|
Monica Mifsud (cousin) |
|||
|
|
|
|
|||
|
Date in |
|
12-Oct |
2002 |
||
|
Date of repair |
|
28-Oct |
2002 |
||
|
Date out |
|
07-Nov |
2002 |
||
|
|
|
|
|||
|
Comments |
|
|
|||
Symptoms observed
BAD |
1 |
No Picture (snowy) |
|
|
|
|
|
|
|
|
GOOD |
1 |
All mechanical and electronical functions
are ok |
|
|
|
|
|
|
2 |
|
Repair notes
Full repair description and observations |
|
|
|
|
|
1 |
When the head ws cleaned, a picture was
obtained, but it was quite snowy. For experience and good job to be done, it
was decided to replace the head. |
|
|
|
|
2 |
The 2-head code was marked VEH0295 in ink
and VJB00D16 marked on the green part |
|
|
|
|
3 |
It was not a difficult task to
remove the head. 1) The head position and any contacts were noted (eg taking phot with
digital camera) 2) The head contacts were firs carefully and well desoldered 3) the head extracter was used to insert scres in the head holes and
gently pull ou the head 4) the new head was inserted back in the exact position of the old
head and resolderd back |
|
|
|
|
4 |
Little control from the rabbits and
audio/control head was required |
|
|
|
|
Repair summary |
VIDEO HEAD REPLACED |
Precautions, fouls and advises |
|
|
|
|
|
1 |
|
Other measurements and technical comments
|
1 |
n/a |
