General information



Job Number



0302-70









Equipment type



 Audio: Stereo Cas/CD/Radio

Made in:

Korea







Maker/Model/Chassis



 ESC

MD-750

??



















Dates

 2003



In

Repaired

Out



Thu.06.Feb

Sat.06.Mar

Thu.11.Mar







Comments









Symptoms observed





1

Sounds distorts badly on all souces (radio/CD/cassette) when volume is increased to normal level





2

No sound from left channel



Repair notes



Full repair description and observations



1

 The first suspect was straight off the audio output IC. This was a cheap IC and would not risk anything to change it. It was KA2206,





2

After it was changed sound was perfect on both channels. The boring thing about this model is that to replace the IC it requires dismantling lots of parts and it was very akward to perform the desoldering of the IC





Repair summary

SOUND OUTPUT IC FAULTY







Precautions, fouls and advises



1

N/a







Other measurements and technical comments



1
