General information
|
Job Number |
|
0303-73 |
|
||
|
|
|
|
|||
|
Equipment type |
|
TV (24 inch) |
Made in: |
|
|
|
|
|
|
|||
|
Maker/Model/Chassis |
|
Seleco |
24SM822 |
? |
|
|
|
|
|
|||
|
|
|
|
|||
|
|
|
|
|||
|
Dates 2003 |
|
In |
Repaired |
Out |
|
|
|
Thu.20.Mar |
Sat.22.Mar |
Sun.23.Mar |
||
|
|
|
|
|||
|
Comments |
|
|
|||
Symptoms observed
|
1 |
No picture, No Raster,
no sound from aerial |
|
|
|
|
2 |
Sound is formed on
video, but picture still absent |
Repair notes
Full repair description and observations |
|
|
|
|
|
1 |
I had a similar fault some time ago on a
Seleco model and this was due a dedicated IC. IT was the TDA 4502 (28pin) but
by mistake I bought the TDA3301b. Fortunately the shop owner took it back and
gave me the money. He did not had a new TDA4502 because they are absolete,
but I obtained one from a scrapped Seleco chassis I had in garage. |
|
|
|
|
2 |
I changed the TDA4502 and the TV came
working well. |
|
Repair summary |
TDA4502 BROKEN DOWN |
Precautions, fouls and advises |
|
|
|
|
|
1 |
It is a brilliant idea
to make a new base when changing large Ics. |
Other measurements and technical comments
|
1 |
N/a |
