Job Number |
|
0303-76 |
|
||
|
|
|
|||
Equipment type |
|
Integrated
Power Audio Amp |
Made in: |
|
|
|
|
|
|||
Maker/Model/Chassis |
|
Ecler |
PAM960 |
|
|
|
|
|
|||
|
|
|
|||
|
|
|
|||
Dates 2003 |
|
In |
Repaired |
Out |
|
|
Mon.31.Mar |
Sat.05.Apr (my birthday) |
|
||
|
|
|
|||
Comments |
|
|
|||
1 |
No sound from one of the
channels |
|
|
2 |
Unit goes into
protection mode |
Full repair description and observations |
|
|
|
1 |
When I opened the set
up, I noted that one of the channels was badly short circuited, few burned
resistors, blown fuse, etc. |
|
|
2 |
There were 10 main
Mosfet type output transistors, 5 IRFP240 and 5 IRFP9240. One set were +ve
and the other –ve driven but I forgot which is which. There were 6 of these
which where short circuit, while 4 still gave good diode check results. The
diode check was not as straight forward as normal transistors giving 0.7V
between b-E and b-c. Sometimes I got 0,5V, and 0,2V and 0.08V readings, but
never 0.00. It appears that the following pattern took place: I get 0.55V
reading, then I check the other junction and I get
0.2V. If I check again the junction which previously gave 0.55, now it will
give 0.08V!! If I check again some other junction, and back again to this
junction, I will get back the 0.55V |
|
|
3 |
Well I searched in the
shops for the transistors and fortunately I found in |
|
|
4 |
I decided to change all
other voltage and biasing transistors, which usually they cost few cents.
There were 8 or 10 to change and about 2 or 3 where short circuit. The
transistors in concern were: BC558b, BC548b, MJE340 (x2), MJE350 (x2) BF871
(x2), BD???. |
|
|
5 |
There was
also 10 12V zenner and 0.22Ohms/5W resistors at the Mosfets ends to be
changed, and some resistors which were burnt out. A 12A fuse was not
available in shops so I used a 10Amp one. I also changed 4 of the
electrolytic capacitor (those at the output stage) |
|
|
6 |
The buying, and
desoldering and soldering took lot of time, as also did the checking and
rechecking of the components not checked. If I miss a component, everything
would burn up again! |
|
|
7 |
Some hard work left to
do was fixing a bad burn in the PCB which cause some tracks to break up.
Fortunately, I could know how things are from the other identical copy
channel. There was only one link, which had to be redone. |
|
|
8 |
I cleaned the circuit
from loose solder and was on the point to switch on. However I was very
afraid that something might be wrong and would cause again a severe damage.
So after long considerations, I decided to buy a variac (7A, 260V (about
1700VA)). The manual also suggests to power up via a variac. |
|
|
9 |
MAPP had a crappy 1000VA
made in china Variac, while G&E had a good built 1700VA model called
Metrel from |
|
|
10 |
I followed the manual of
the amplifier which said that I should supply ac via a variac, starting from
0V and gradually increase the voltage. I have to connect an ammeter along one
of the fuses of the channel (the other fuse should be in place). When I see a
current overload more from 0.8A I should stop increasing the ac voltage and
turn off the amp and check for something wrong. This will prevent severe
damage to the channel. |
|
|
11 |
I did this, but I made 2
mistakes (see below in the precautions). I started to increase the voltage, ammeter remained always 0Amps, so I continued to
increase the voltage. Around 100Vac, I heard a crackling sound, one of the
resistors produced smoke, and I switched off quickly the amp. I checked what
happened and found out 2 power transistors got short circuit, as well as 2
diodes, resistors and high wattage resistors. Not much damage but still I was
very discouraged. |
|
|
12 |
Next day (my birthday) I
decided to change the faulty components and try again. I realised of two critical mistakes. The
ammeter was set to read ac current not dc current and I did not fixed the
circuit to the heat sink, so excess heat may have broken the ‘heat fragile’
Mosfets. |
|
|
13 |
Everything was
desoldered back and I was again trying to increase the voltage with the
variac. On 110Vac, the amp was just 0.2A. The critical value (according Ecler
manual) was 0.8A so I was on the good track. I increased further the voltage
until I finally arrived to 240V ac. And the current was 0.5A approx. |
|
|
14 |
The manual continues
saying that there should be 0.07A per transistor pair, hence in this case 0.07A
x 5 = 0.35A. To adjust this current there was a special preset. I altered the
value until I got 0.35A. I found out that the other ‘good’ channel had a
current reading of 0.7A. I adjusted it back to 0.35A. Probably the user has
tweaked with these pots to get more powerful sound ?!? |
|
|
15 |
There where some more
settings to do but using an oscilloscope. Since I do not posses one, I could
not make these adjustment. I switched on the amp for
5 hours and the current drifted slightly to 0.40A due to heat production, so
I compensated and adjusted the pot so that when hot the current reads 0.37A.
(When cold, initial current was now 0.33A). |
|
|
16 |
The amp was connected to
a speaker and a sound input was applied.
|
Repair summary |
CHANNEL
SEVERLY SHORT CIRCUIT, VARIOUS COMPONENTS INCLUDING TRANSISTORS NEED TO BE
REPLACED |
Precautions, fouls and advises |
|
|
|
1 |
When reading current, be
sure that you select the correct form between ac and dc. In circuit, the
current should be read almost always in dc form (like voltages). By mistake I
placed the reading on ac and I always had a 0 reading. So I did not realised about the current build up (and thought that
ammeter was faulty!!!) |
|
|
2 |
Mosfets, esp. in such power amplifiers are heat sensitive
and if not connected to heat sink, even for short testing periods, they can
get damaged and develop short circuit. Always connect circuit to heat sink as
in the original state before testing. |
|
|
3 |
The variac is a very
important tool when it comes to power amplifiers, and faults which consists
of high current damage. The procedure is like this! You connect a dc ammeter
to a fuse (not being mains ac fuse) or in series after a voltage supply
resistor. You connect the item under test to the variac and increase the
voltage slowly. If you note a build up of current (1g 1A and above) at quite
low voltages (eg 110V) then there is something wrong. The faulty component
could be easily identified by seeing which component gets very hot!!! J |
1 |
N/a |
