General information
|
Job Number |
|
0304-79 |
|
||
|
|
|
|
|||
|
Equipment type |
|
VCR |
Made in: |
|
|
|
|
|
|
|||
|
Maker/Model/Chassis |
|
Akai |
VS965 EO |
|
|
|
|
|
|
|||
|
|
|
|
|||
|
|
|
|
|||
|
Dates 2003 |
|
In |
Repaired |
Out |
|
|
|
Tue.15.Apr |
Thu.17.Apr |
Fri.18.Apr |
||
|
|
|
|
|||
|
Comments |
|
|
|||
Symptoms observed
|
1 |
No Fast Forward, No
Rewind, No Play |
|
|
|
|
2 |
Sound of capstan motor
spinning fast fro few seconds then VCR goes back to stop mode |
|
|
|
|
3 |
Counter does not work on FF / REW / Play |
Repair notes
Full repair description and observations |
|
|
|
|
|
1 |
On examining the fault
there was tw things which could been wrong. The
belts are loose or the idler clutch was jammed / blocked |
|
|
|
|
2 |
First I changed the
belts (which to my opinion they weren’t much loose) but still the new ones
were more ‘tight’. This solved the problem, but I don’t excluded
that with maniuvring the clutch got freed back to normal. I have this opinion
because as I said the original belts where not that much in a bad
shape. |
|
|
|
|
Repair summary |
BELTS WHERE CHANGED |
Precautions, fouls and advises |
|
|
|
|
|
1 |
N/A |
Other measurements and technical comments
|
1 |
These are the Power supply voltages found when OFF and STOP mode
|
