My Repair Jobs
General information
Job Number |
|
0010-02 |
|
|
|
|
|
||
Equipment type |
|
Home synthesiser |
||
|
|
|
||
Maker + Model # |
|
Yamaha PSR ?400? |
||
|
|
|
||
Made in |
|
Japan |
|
|
Symptoms observed
BAD |
1 |
Keys C0, F#0, C1 do not produce sound when pressed |
|
|
|
|
|
|
GOOD |
1 |
Powers up |
|
|
|
|
2 |
Good sound output |
|
|
|
|
3 |
Rest of and panel controls work good |
Repair notes
Repair summary |
OPEN TRACK IN KEYBOARD
MATRIX |
Full repair description and observations |
|
|
|
1 |
When the synth was opened, there was a set of diodes on a separate PCB
strip over the keyboard section “keyboard matrix” |
|
|
2 |
All the diodes had a steady 5V, except 3, which gave a fluctuating
voltage and also did correspond with the respective faulty keys |
|
|
3 |
The keyboard matrix was opened and after some inspection an open track
was observed. The track, which was corroded, supplied 5V on the 3 faulty keys |
|
|
4 |
The track was joined by a solid core wire and the keys now worked
perfectly |
