My Repair Jobs
General information
Job Number |
|
0010-04 |
|
|
|
|
|
||
Equipment type |
|
Car Stereo Radio Cassette |
||
|
|
|
||
Maker + Model # |
|
MATSUI
3110Xqi |
||
|
|
|
||
Made in |
|
Korea |
|
|
|
|
|
||
Comments |
|
|
||
Symptoms observed
BAD |
1 |
No sound output from
left channel (blue + green connection) |
|
|
|
|
2 |
Cassette non operational
– no rotation of the pinch roller, etc |
|
|
|
|
3 |
Over heating of the back
panel (location of the power audio transistors) |
|
|
|
|
|
|
GOOD |
1 |
Right channel sound OK |
|
|
|
|
2 |
Powers up, etc |
|
|
|
|
3 |
Cassette motor functions
well (can be heard operating) |
|
|
|
Repair
notes
Repair summary |
1)
FAULTY
AUDIO POWER AMPLIFIER 2)
MOTOR
CHAIN OUT OF POSITION |
Full repair description and observations |
|
|
|
Fault A: No sound at left channel |
|
|
|
1 |
When the item was
opened, it was noted that one of the power amps was very, very hot. |
|
|
2 |
The voltages at the pins
of the 2 ICs were compared and the results are shown in Table 1 (below).
There were different readings and the faulty IC had mysterious same voltage
levels between 2 pairs of adjacent pins (short circuit -> heat dissipation
?) |
|
|
3 |
The suspected and the
good power amps were desoldered, removed from position and checked for their
internal resistance between the pins. The results are shown in table 2
(below). It was concluded that the IC was faulty and bought a new one. |
|
|
4 |
The audio amp was a
Single in Line, 12-pin IC – LA 4445. Pinout is shown in table 3 (below) |
|
|
5 |
I also checked the
voltages at the chip track slots (were the chip was soldered) to ensure that
the IC was not burnt out due to an abnormal high voltage or short circuit at
any pins. Both sides had a 12V supply at pin 9 and the rest had a couple of
milliVolts |
|
|
6 |
I replaced the faulty
IC, and added new heat transfer material, powered up and the faulty left channel
played successfully. |
|
|
Fault B: Cassette non functioning, but motor sounds running |
|
|
|
1 |
This is atypical case of
a slipped motor/pulley chain, so the cassette section was disassembled out. |
|
|
2 |
The chain was in fact
out of position, and hence was loaded back into place. |
|
|
3 |
When the cassette was
assembled back, and tested with a tape, it did a strange grinding noise and
also jumbled the tape magnetic strip. |
|
|
4 |
On inspection of this
problem, it was noted that the rotators were moving in opposite direction,
and concluded that this was due to placing the motor/pulley chain in a wrong
position. |
|
|
5 |
Instead of disassembling
the cassette again, the dc motor voltage supply polarity was invades (also
inverting the parallel capacitor) by ex-changing the voltage supply +ground
wires |
|
|
6 |
On testing, the cassette
operating excellently! |
Precautions, fouls and advises |
|
|
|
1 |
While desoldering the
IC, excessive heat caused some track
slots to break. |
|
|
2 |
The desoldering wick was much better from the suction pump for
desoldering IC pins |
|
|
3 |
Disassembling and
assembling of the cassette was a very tricky job to do, and can easily lead
to confusion when assembling back. The best thing is to note every section of the cassette how it is positioned, and write
the observations on paper. |
|
|
4 |
Loading back the
motor/pulley chain is not just a job of putting it in the grooves. One should
study the direction of rotation of the
motor in respective with the direction of the playback of the tape, in
order to fit the chain as originally was. In this case the chain was placed
wrong! |
|
|
5 |
If the playback results
in grinding clicking sound, and plastic slips sound, it is very probable that
the rotation is operating in the
opposite direction. In this case, practice showed that inverting the motor polarity would effectively solve the problem! |
|
|
6 |
During assembling back,
the eject cassette push lever was
not in place, and the eject system was non-operative. Excessive pressure
broke a small part of this plastic mechanical part, but fortunately it was
not critical. This should extend from the backside of the cassette, (approx.
parallel to the side) to about 45 degrees inwards, near the first cassette
roller. |
|
|
7 |
Always note the
impedance output of the amplifiers, in order to test the sound with speakers of the right impedance. Never use
speakers of lower impedance from that of the amps output |
|
|
Replaced parts + info
## |
Spare part item
description |
Shop / source |
Price / LM |
|
|
|
|
01 |
LA4445 IC (Audio power amp, SIL) |
Mapp electronix |
LM1.16 |
Prices
Approx. working time |
4 |
hours |
|
|
|
Fault Difficulty Level |
4 |
out of 10 |
|
|
|
Total price for parts |
LM |
1.20 |
|
|
|
Final repairing price |
LM |
2.00 |
Other
measurements and technical comments
1 |
See tables below |
Table
1: Comparison of the voltage at the pins of the two
Audio Power Amps. |
||||
Pin |
Good IC |
Suspected IC |
Pin function |
Observation |
|
|
|
|
|
1 |
1.2V |
0.7V |
RC chain to left ground |
OK |
2 |
16mV |
315mV |
Right input |
OK |
3 |
4mV |
10mV |
Ground |
OK |
4 |
11V |
2V |
C to Ground |
2V Low ? |
5 |
3mV |
9mV |
Left input |
OK |
6 |
1.2V |
1.6V |
RC chain to right ground |
OK |
7 |
10.4V |
2.7V |
C to out left |
2.7V Low ? |
8 |
5.9V |
2.7V |
Out left |
Short circuit with pin 7
? |
9 |
11.9V |
11.7V |
Vcc |
OK |
10 |
5.9V |
2.3V |
Out right |
2.3V Low ? |
11 |
10V |
2.3V |
C to out right |
Short circuit with pin
10 ? |
12 |
0V |
0V |
Ground |
OK |
Table
2: Comparison of the internal resistance between pins
of a good & faulty LA4445 (Audio Power Amp.) |
||||||||||
Test pins |
Good |
Faulty |
|
Test pins |
Good |
Faulty |
|
Test pins |
Good |
Faulty |
|
|
|
|
|
|
|
|
|
|
|
Pin 12 – 11 |
10k |
Inf |
|
Pin 10 – 9 |
1k |
600 |
|
Pin 7 – 6 |
30k |
Inf |
10 |
580 |
510 |
|
8 |
1k |
15k |
|
5 |
4M |
Inf |
9 |
1k |
150 |
|
7 |
10k |
Inf |
|
4 |
11k |
Inf |
8 |
580 |
15k |
|
6 |
20k |
28k |
|
3 |
4M |
Inf |
7 |
10k |
Inf |
|
5 |
4M |
4M |
|
2 |
4M |
Inf |
6 |
20k |
27k |
|
4 |
1.6k |
1k |
|
1 |
30k |
Inf |
5 |
4M |
4M |
|
3 |
4M |
4M |
|
|
|
|
4 |
1.6k |
650 |
|
2 |
4M |
4M |
|
Pin 6 –5 |
4M |
3M |
3 |
4M |
4M |
|
1 |
20k |
2M |
|
4 |
22k |
22k |
2 |
4M |
4M |
|
|
|
|
|
3 |
4M |
4M |
1 |
20k |
2M |
|
Pin 9 – 8 |
1k |
154 |
|
2 |
4M |
4M |
|
|
|
|
7 |
10k |
Inf |
|
1 |
43k |
2.2M |
Pin 11 – 10 |
9k |
Inf |
|
6 |
20k |
27k |
|
|
|
|
9 |
10k |
Inf |
|
5 |
4M |
4M |
|
Pin 5 – 4 |
Inf |
1.3M |
8 |
10k |
Inf |
|
4 |
500 |
500 |
|
3 |
31k |
5M |
7 |
20k |
Inf |
|
3 |
4M |
4M |
|
2 |
63k |
5M |
6 |
30k |
Inf |
|
2 |
4M |
4M |
|
1 |
Inf |
3M |
5 |
4M |
Inf |
|
1 |
20k |
2M |
|
|
|
|
4 |
11k |
Inf |
|
|
|
|
|
Pin 4 –3 |
4M |
4M |
3 |
4M |
Inf |
|
Pin 8 – 7 |
9k |
Inf |
|
2 |
4M |
4M |
2 |
4M |
Inf |
|
6 |
19k |
31k |
|
1 |
22k |
2M |
1 |
29k |
Inf |
|
5 |
4M |
4M |
|
|
|
|
|
|
|
|
4 |
1.6k |
600 |
|
Pin 3 – 2 |
30k |
28k |
Grey = faulty |
|
|
|
3 |
4M |
4M |
|
1 |
Inf |
10M |
|
|
|
|
2 |
4M |
4M |
|
|
|
|
Pins 1,7,11 |
|
|
|
1 |
20k |
2M |
|
Pin 2 - 1 |
Inf |
10M |
Open circuit |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Table 3: Specifications and Pinouts of the LA4445
Audio Power Amp IC. |
LA4445 Power amplifier Power Output: 2 x 5.5 W Impedance: 2 x 3 ohm P(out) (U = 16V) 5.5 W U dc. Min = 8V U dc. Max = 24V U in. = 0.25V Gain = 48db f = 30Hz-20KHz Noise (P out=5W) = 64db Pinouts: pin 1 - RC chain to ground ("Right" cannel) pin 2 - Input "Right" pin 3 - Ground pin 4 - C to Ground pin 5 - Input "Left" pin 6 - RC chain to ground ("Left" cannel) pin 7 - C to out ("Left" cannel) pin 8 - Out ("Left" cannel) pin 9 - U dc (VCC) pin 10 - Out ("Right" cannel) pin 11 - C to out ("Right" cannel) pin 12 - Ground C – capacitor ---||--- ___ RC chain ---||---| R |---
|
