My Repair Jobs
General information
|
Job Number |
|
0010-06 |
|
|
|
|
|
|
||
|
Equipment type |
|
Radio cassette double deck recorder |
||
|
|
|
|
||
|
Maker + Model # |
|
SANYO MW-806L(k) |
||
|
|
|
|
||
|
Made in |
|
? |
|
|
|
Comments |
|
Reported to record sound badly (pitching the sound
in a disgusting way) |
||
Symptoms observed
BAD |
1 |
Playback (and record) on
Deck B is faulty - sound out of tone |
|
|
|
|
|
|
|
|
GOOD |
1 |
Deck A fully operational |
|
|
|
|
|
|
2 |
Deck B - Fast forward / Rewind / Pause etc OK |
|
|
|
|
Repair
notes
|
Repair summary |
PINCH ROLLER HEAVILY DIRTY |
Full repair description and observations |
|
|
|
|
|
1 |
As deck B was compared
with deck A (which worked fine), no faulty mechanism was noted. |
|
|
|
|
2 |
The mechanism was
serviced with the Contact Cleaner spray, and the pinch roller was cleaned up
with 100% isopropyl alcohol. It was evident that the pinch roller was heavily
dirty. |
|
|
|
|
3 |
After few minutes, the
equipment was tested and playback resumed correctly, and so did the
recording. |
Precautions, fouls and advises |
|
|
|
|
|
1 |
Always take care of how
the parts were assembled so that when put things back together, it won’t be a
difficult task. Preferably note/draw how the removed parts were |
