Job Number |
|
0010-08 |
|
|
|
|
|
||
Equipment type |
|
Audio stereo receiver Amplifier |
||
|
|
|
||
Maker + Model # |
|
YAMAHA R-300 |
||
|
|
|
||
Made in |
|
|
|
|
Comments |
|
1)
Was
bought second hand, very old judging from the rusty back panel, nice tuning mechanism. 2)
The
cost of the broken IC was very expensive for the owner and decided not to fix
the equipment. |
||
Symptoms
Observed
BAD |
1 |
No Sound Output |
|
|
|
|
2 |
No Relay click after
start up. |
|
|
|
|
|
|
GOOD |
1 |
Tuner back display and
tuning pointer lights up |
|
|
|
|
2 |
No part of the circuit
produces excessive heat |
|
|
|
Repair
notes
Repair summary |
BROKEN AF POWER AMP IC STK2030 II |
Full repair description and observations |
||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||
1 |
First suspicion fell on
the power supply. The 2 reservoir capacitors (connected in series) did supply
the +41V and 41V to the amplification circuit. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
2 |
The amplification system mainly consisted of two large ICs : 1) STK3042 a
Voltage amplifier and 2) STK2030II an
Audio Power Amplifier. These were symmetrical ICs, and the pins from the centre to the left
were identical to the pins from the centre to the right. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
3 |
The voltage at the pins
of the two ICs were taken and compared. The voltages of the two sides
(channels) of each IC were not equal, as shown below. The pinouts given below
are theoretical assumption from the datasheets found on the internet. (The
ICs are Sanyo). |
|||||||||||||||||||||||||||||||||||||
STK 3042 (Voltage
Amplifier) |
STK 2030 (AF Power
Amplifier) |
|||||||||||||||||||||||||||||||||||||
Pin |
Function |
Voltages |
Pin |
Function |
Voltages |
|||||||||||||||||||||||||||||||||
(a) |
(b) |
(c) |
(a) |
(b) |
(c) |
|||||||||||||||||||||||||||||||||
1 |
Input |
-43mV |
-50mV |
0 |
1 |
L: Input (+) |
- 9.2 V |
42 V |
0 |
|||||||||||||||||||||||||||||
2 |
Input |
-43mV |
-50mV |
0 |
2 |
+ Vcc |
41 V |
42 V |
42 V |
|||||||||||||||||||||||||||||
3 |
Output ? |
40 V |
41 V |
0 |
3 |
Output (+) |
-40mV |
-50mV |
0 |
|||||||||||||||||||||||||||||
4 |
Output ? |
40 V |
41 V |
0 |
4 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
5 |
Output ? |
- 11.2V |
- 42 V |
0 |
5 |
Output (-) |
-40mV |
-50mV |
0 |
|||||||||||||||||||||||||||||
6 |
Output ? |
- 9.2V |
42 V |
0 |
6 |
- Vcc |
- 42 V |
- 42 V |
- 42 V |
|||||||||||||||||||||||||||||
7 |
Vcc - |
- 41 V |
- 42 V |
- 42V |
7 |
Input (-) |
- 11.2V |
- 42 V |
0 |
|||||||||||||||||||||||||||||
8 |
GND |
0 |
0 |
0 |
8 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
9 |
Vcc + |
+41 V |
42 V |
42 V |
9 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
10 |
Output ? |
7.5V |
42 V |
0 |
10 |
R: Input (+) |
5.1 V |
- 42 V |
0 |
|||||||||||||||||||||||||||||
11 |
Output ? |
5.1V |
- 42 V |
0 |
11 |
+ Vcc |
- 42 V |
- 43 V |
- 42 V |
|||||||||||||||||||||||||||||
12 |
Output ? |
41 V |
41 V |
0 |
12 |
Output (+) |
16 V |
- 50mV |
0 |
|||||||||||||||||||||||||||||
13 |
Output ? |
40 V |
41 V |
0 |
13 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
14 |
Input |
16 V |
-50 mV |
0 |
14 |
Output (-) |
16 V |
-50mV |
0 |
|||||||||||||||||||||||||||||
15 |
Input |
7 V |
-50 mV |
0 |
15 |
- Vcc |
41.5 V |
42V |
42 V |
|||||||||||||||||||||||||||||
|
|
|
|
|
16 |
Input (-) |
7 V |
42V |
0 |
|||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||||||||||
(a) Both ICs in place |
(b) STK2030 removed |
(c) Both ICs removed |
||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
4 |
It was noted that on pin
1 and 2 of the STK3042 there was no voltage (0.1V), while on the equivalent
pins of the other channel (pins 14 and 15) there was 15V and 7V. These
voltages were routed to/from pins 3 and 5 (also 14 and 12) of the STK 2030. |
|||||||||||||||||||||||||||||||||||||
5 |
Test points on the PCB
were labelled 15V and 15V, of which the 15V were found, while the +15V were
not found. It is assumed that these are the voltages to be found under
operating conditions. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
6 |
The source of the +15
and 15V was not determined, and hence could not solve the problem. It is not
excluded that these voltages come directly from any of the STK ICs and hence
the lack of these voltages indicates that any of the ICs is broken. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
7 |
On desoldering the
STK2030 Power amp, the relay did click, and not bot voltages at the input
became 0.1V. This is an indication that the STK2030 is broken, but not prove
is found to confirm this, especially when checking all pins with the diode
test, the results were symmetrical but some were not as theoretically
demonstrated on the data sheet equivalent circuit. The significant results
(those which gave a reading) are shown below while the full results are shown
in Table 1 (under other measurements) |
|||||||||||||||||||||||||||||||||||||
Pin Pin Diode Test |
Fow (L) |
Fow (R) |
Rev (L) |
Rev (R) |
Pin Pin Diode Test |
Fow (L) |
Fow (R) |
Rev (L) |
Rev (R) |
|||||||||||||||||||||||||||||
Pin 1 2 |
0.6 |
0.6 |
/ |
/ |
Pin 3 4 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
3 |
1.0 |
1.0 |
/ |
/ |
5 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
4 |
/ |
/ |
/ |
/ |
6 |
/ |
/ |
1.1 |
1.1 |
|||||||||||||||||||||||||||||
5 |
/ |
/ |
/ |
/ |
7 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
6 |
/ |
/ |
1.7 |
1.7 |
|
|
|
|
|
|||||||||||||||||||||||||||||
7 |
1.2 |
1.1 |
1.4 |
1.4 |
Pin 4 5 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
|
|
|
|
|
6 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
|
|
|
|
|
7 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
Pin 2 3 |
/ |
/ |
/ |
/ |
|
|
|
|
|
|||||||||||||||||||||||||||||
4 |
/ |
/ |
/ |
/ |
Pin 5 - 6 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
5 |
/ |
/ |
/ |
/ |
7 |
/ |
/ |
/ |
/ |
|||||||||||||||||||||||||||||
6 |
/ |
/ |
1.1 |
1.1 |
|
|
|
|
|
|||||||||||||||||||||||||||||
7 |
/ |
/ |
1.7 |
1.7 |
Pin 6 7 |
0.6 |
0.6 |
/ |
/ |
|||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
8 |
The Voltage amp
(STK2030) was also desoldered and the Diode test was performed between its
pins to note any differences. Pin 7
and the complementary pin 9 showed some differences to some pins, but this
might be due the fact that pin 7 takes a positive VCC while pin 9 takes a
negative VCC voltage, and hence the internal circuit is different between pin
7 and 9. |
|||||||||||||||||||||||||||||||||||||
Pin Pin Diode Test |
Result (Forw) |
Pin Pin Diode Test |
Result (Forw |
Pin Pin Diode Test |
Result (Forw |
Pin Pin Diode Test |
Result (Forw |
|||||||||||||||||||||||||||||||
Pin 1 3 |
1.3 |
Pin 15 13 |
1.3 |
Pin 9 12 |
0.6 |
Pin 9 - 3 |
0.6 |
|||||||||||||||||||||||||||||||
Pin 1 4 |
0.7 |
Pin 15 12 |
0.7 |
Pin 9 13 |
0.6 |
Pin 9 4 |
0.6 |
|||||||||||||||||||||||||||||||
Pin 2 3 |
0.7 |
Pin 14 13 |
0.7 |
Pin 10 12 |
1.3 |
Pin 6 4 |
1.4 |
|||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|||||||||||||||||||||||||||||||
Pin 6 9 |
1.1 |
Pin 10 9 |
1.1 |
Pin 10 13 |
1.3 |
Pin 6 3 |
1.4 |
|||||||||||||||||||||||||||||||
Pin 6 12 |
1.5 |
Pin 10 4 |
1.5 |
Pin 12 13 |
0.6 |
Pin 4 3 |
0.6 |
|||||||||||||||||||||||||||||||
Pin 6 13 |
1.5 |
Pin 10 3 |
1.5 |
|
|
|
|
|||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|||||||||||||||||||||||||||||||
Note the symmetry of results between column 2 4
and 6 8. |
||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
9 |
At this point it was obvious that one of the IC was
broken, and to confirm things out, many of the components around the IC were
checked and found to be OK. These included many resistors, 3 transistors and
about 4 capacitors. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
10 |
The STK3042 was mounted back in place, and one
channel of the STK2030 AF Amp was also mounted. The channel mounted was the
good one, were the 15V were found. On powering up, the relay did not
clicked, indicating that there is a fault! |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
11 |
Still puzzled, this channel was desoldered again,
while the channel which it was suspected to be faulty (were there was no 15V
found) was soldered back. The set was powered up, and with a surprise, not
only that the relay click was
obtained, but the sound output was given out (via the headphone jack).
Thus the faulty channel is that were the 15V are present while the good
channel were there was -0.1V. |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
12 |
The voltages of the STK3042 (fully connected to PCB)
and those of the STK2030 (with the faulty channel not connected) were
measured and the results obtained are as follows: |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
13 |
STK 2030 AF Power Amp (faulty channel pins
10-16 disconnected) |
STK3042 Voltage
amplifier fully connected (faulty side pins 9-15) |
||||||||||||||||||||||||||||||||||||
Faulty |
Good |
|
Faulty |
Good |
|
|||||||||||||||||||||||||||||||||
Pin |
Voltage |
Pin |
Voltage |
Function |
Pin |
Voltage |
Pin |
Voltage |
Function |
|||||||||||||||||||||||||||||
16 |
40V |
1 |
-2.8V |
Input |
15 |
-70mV |
1 |
-40mV |
Input |
|||||||||||||||||||||||||||||
15 |
41V |
2 |
42V |
VCC + |
14 |
-70mV |
2 |
-40mV |
Input |
|||||||||||||||||||||||||||||
14 |
-135mV |
3 |
7mV |
Output |
13 |
40V |
3 |
+40V |
? |
|||||||||||||||||||||||||||||
13 |
/ |
4 |
/ |
/ |
12 |
40V |
4 |
+40V |
? |
|||||||||||||||||||||||||||||
12 |
-135mV |
5 |
6mV |
Output |
11 |
-41V |
5 |
-5.3V |
Output |
|||||||||||||||||||||||||||||
11 |
-42V |
6 |
-42V |
VCC - |
10 |
40V |
6 |
-2.8V |
Output |
|||||||||||||||||||||||||||||
10 |
-42V |
7 |
-5.3V |
Input |
9 |
+41V |
7 |
-41V |
VCC |
|||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
14 |
I resoldered the 3042 in place and began a series of
tests to check whether one of the channels is not operating due to a faulty
channel in the Power amp (STK2030), or a faulty output from the Voltage
amplifier (STK3042). The test s are
performed as shown below: |
|||||||||||||||||||||||||||||||||||||
Test applied on 2030
|
Relay Click |
Sound o/p |
Comments |
Voltage readings (2030) |
||||||||||||||||||||||||||||||||||
Pin 10 (i/p) |
Pin 16 (i/p) |
Pin 12 (o/p) |
Pin 14 (o/p) |
|||||||||||||||||||||||||||||||||||
1 |
Exchange input
from working channel to faulty channel. |
No |
No |
If the sound was produced, then the 2030 channels
are both OK, but now it means that one
channel of the 2030 is broken |
/ |
/ |
16V |
16V |
||||||||||||||||||||||||||||||
2 |
Desolder input and output of faulty channel |
Yes |
No |
The problem is with the signal routing (i/p or o/p) |
/ |
/ |
16V* |
16V* |
||||||||||||||||||||||||||||||
3 |
Desolder output of faulty channel (input is connected) |
Yes |
No |
The problem is with the output of the faulty
channel. It is giving of a 16V which may be a means of protection to switch
off the relay and prevent further damage to the speakers |
5V |
7V |
16V* |
16V* |
||||||||||||||||||||||||||||||
4 |
Connect output from 3042 faulty side to good side
of the 2030 |
Yes |
Yes |
Confirmed. 3042 working perfectly, one channel of
the 2030 is broken, the other one is
OK |
-5V |
-8V |
0.5V |
0.5V |
||||||||||||||||||||||||||||||
5 |
Connect output from one side of 3042 to inputs of both sides of 2030. |
No |
No |
The faulty channel produced those 16V and turned off
the relay. |
|
|
16V |
16V |
||||||||||||||||||||||||||||||
* The
voltages are measured from the desoldered pins of the IC. Since these are not
connected to the track, the
..relay
does not sense the presence of the16V and so it operates |
||||||||||||||||||||||||||||||||||||||
n.b. The
voltages measured are volume dependent. If the volume is increased, the voltage
varies accordingly. |
||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
15 |
The inputs and outputs of the faulty channel of the
2030 was desoldered so that the amplifier will operate at least on one
channel (one speaker). |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
16 |
Finally the knobs were serviced with contact spray
for better operation |
|||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||
Precautions, fouls and advises |
|
|
|
1 |
|
Other
measurements and technical comments
1 |
The
relay is a component with at least 6 pins. 2 of these are connected to a
solenoid coil. The other 2 pairs are pins of 2 switch contacts. When DC
voltage is passed through the coil, the core gets magnetised and pulls an iron lever, which in turn cause
the 2 switches to close. The resistance of the coil was 500 Ohms, and during
operation, one was terminal was 23V, while the other was 150mV. When both
sides were 23V (no voltage drop) the relay did not operate (close). |
|||||
|
|
|||||
2 |
Table 1: Diode test pin
combination for the IC STK2030 (Voltage amplifier) |
|||||
|
Pin Pin Diode Test |
Fow |
Rev |
Pin Pin Diode Test |
Fow |
Rev |
Pin 1 2 |
/ |
/ |
Pin 6 7 |
/ |
/ |
|
3 |
1.25 |
/ |
8 |
/ |
/ |
|
4 |
0.72 |
/ |
9 |
1.1 |
/ |
|
5-15 |
/ |
/ |
10 |
/ |
/ |
|
|
|
|
11 |
/ |
/ |
|
Pin 2 3 |
0.71 |
/ |
12 |
1.5 |
/ |
|
4-15 |
/ |
/ |
13 |
1.5 |
/ |
|
|
|
|
14-15 |
/ |
/ |
|
Pin 3 4 |
/ |
0.6 |
|
|
|
|
5 |
/ |
/ |
Pin 7 - * |
/ |
/ |
|
6 |
/ |
1.35 |
|
|
|
|
7 |
/ |
/ |
Pin 8 - * |
/ |
/ |
|
8 |
/ |
/ |
|
|
|
|
9 |
/ |
0.6 |
Pin 9 10 |
/ |
1.1 |
|
10 |
/ |
1.51 |
11 |
/ |
/ |
|
11-15 |
/ |
/ |
12 |
0.62 |
/ |
|
|
|
|
13 |
0.6 |
/ |
|
Pin 4 5 |
/ |
/ |
14-15 |
/ |
/ |
|
6 |
/ |
1.35 |
|
|
|
|
7 |
/ |
/ |
Pin 10 11 |
/ |
/ |
|
8 |
/ |
/ |
12 |
1.25 |
/ |
|
9 |
/ |
0.6 |
13 |
1.23 |
/ |
|
10 |
/ |
1.5 |
14-15 |
/ |
/ |
|
11-15 |
/ |
/ |
|
|
|
|
|
|
|
Pin 11 - * |
/ |
/ |
|
Pin 5 - * |
/ |
/ |
|
|
|
|
|
|
|
Pin 12 13 |
0.58 |
/ |
|
|
|
|
14 |
/ |
/ |
|
|
|
|
15 |
/ |
0.7 |
|
Pin 14 15 |
/ |
/ |
|
|
|
|
|
|
|
Pin 13 14 |
|
0.74 |
|
|
|
|
15 |
|
1.27 |
|
|
|
|||||
3 |
Included below are the
datasheets for the STK3042 and the STK2230 family (2030 not included but
similar circuits are demonstrated). Obtained from Yahoo search (site =
laboratories of |
