General information
|
Job Number |
|
0103-21 |
|
|
|
|
|
|
||
|
Equipment type |
|
Video Cassette Recorder |
||
|
|
|
|
||
|
Maker + Model # |
|
Matsui VP-9605 |
||
|
|
|
|
||
|
Made in |
|
? |
|
|
|
|
|
|
||
|
Comments |
|
The vcr seams to have no tracking functions?! |
||
Symptoms observed
BAD |
1 |
Cassette is ejected back
for no particular reason |
|
|
|
|
|
|
|
|
GOOD |
1 |
Powers up, good logic
display |
|
|
|
|
|
|
2 |
Motors working properely |
|
|
|
|
Repair notes
Full repair description and observations |
|
|
|
|
|
1 |
Not much to say, the vcr
was opened and the cassette seemed to be ejected for no reason. On inspecting
the cassette housing assembly, two springs were noted to be out of place. |
|
|
|
|
2 |
1 of the springs was
loaded back into position, while the other was then known that it served as
an earth connection with the top cover and one of its ends was susoended
upwards. |
|
|
|
|
3 |
This seemed that it
fixed the problem, but it is not excluded that the solution could have been
that of cleaning the tape detector prisms during testing and manipulation. |
|
|
|
|
4 |
There seemed to be no
other problems and the VCR worked perfectly. |
|
Repair summary |
TENSION SPRING IN CASSETTE LOADING ASSEMBLY OUT OF
PLACE |
Precautions, fouls and advises |
|
|
|
|
|
1 |
N/a |
