General information



Job Number



0107-25









Equipment type



Seleco TV 19 inch







Maker + Model #



19SM???







Made in













Comments





Remote control lost (not given)







 Symptoms observed



BAD

1

When program button is pressed to activate the TV to normal use, it remains on stand-by mode.









2

Front pannel switch buttons are absent (broken away) and the user pushes directly the microswitches buttons.













GOOD

1

Stand by mode ok











  Repair notes



Full repair description and observations



1

On observing the front panel microswitches, 2 of them were rusty. On checking their functionality with the continuity meter, it was fiund that they lost contact and were open on both On/Off States.





2

3 of the 5 microswitches were replaced, the other 2 seems in perfect order. Now the Tv switched on from standby on pressing the Prog + button. (the other 4 buttons are not designed tp turn on the TV from stand)





3

The front panel push buttons were bought from RTV, Marsa





4

They were not exactly compatible with the current model, but by doing alteration they were made to fit inside and function perfectly.





5

The Prog+ button was painted green, and function labels were drawn and printed on the computer and afixed under the buttons - for aesthetic purposes.





Repair summary

Open Front panel micro switch
