General information
Job Number |
|
0108-26 |
|
|
|
|
|
||
Equipment type |
|
Video Colour Recorder |
||
|
|
|
||
Maker + Model # |
|
Fischer ??? |
||
|
|
|
||
Made in |
|
|
|
|
|
|
|
||
Comments |
|
|
||
BAD |
1 |
Play, RW, FF not
operative – video resets itself to standby |
|
|
|
|
|
|
GOOD |
1 |
Powers up perfecetly |
|
|
|
|
2 |
Load and Eject tape
works OK |
Full repair description and observations |
|
|
|
1 |
Initially, a dried
capacitor in the power supply was the first suspect, but on a qucik voltage
test, all outputs were given OK |
|
|
2 |
On operating the video
it was noted that the main belt which drived the gear mechanism from the main
capstan motor was loosey |
|
|
3 |
A new belt of same
thickness and diameter was repalced and the VCR came to work perfectely. |
Repair summary |
Capstan Motor Belt old and loosey |
Precautions, fouls and advises |
|
|
|
1 |
To remove the belt from
its place, a number of parts around the the switch mode and motor had to be
removed. To avoid remounting problems, every sing action and item removed was
noted down on paper. When remounting the reverse actions were done, and the notes helped very much to make everything in order and as it was
originally performed. |
