My Repair Jobs
Job Number |
|
0201-33 |
|
|
|
|
|
||
Equipment type |
|
Television |
||
|
|
|
||
Maker + Model # |
|
Seleco 25SM361 |
||
|
|
|
||
Made in |
|
|
|
|
|
|
|
||
Comments |
|
|
||
BAD |
1 |
Pin cushion distortion,
and reduced raster width |
|
|
|
|
|
|
GOOD |
1 |
Good picture detail
(Chroma and Luma) and sound |
|
|
|
Full repair description and observations |
||||
|
||||
1 |
Assuming that the pin
cushion / east west correction IC (TDA 8145) was faulty, I replaced it and
turned the Tv on. There was no pin cushion distortion and the Tv was tested
for about 4 hours or so. |
|||
|
|
|||
2 |
I gave the TV to the
Client, but the day after he quarrel that there was again the same problem. I
took the TV back to home and analysed the problem. The problem sometimes
appeared and sometimes not. When the board was tampered slightly, the fault
did come and go. So it was obvious that it was a dry joint somewhere in the
pin-cushion circuitry. |
|||
|
|
|||
3 |
I resoldered as many
points as possible and turned the TV on. The problem was not formed, and even
when tampering slightly on the circuits board / pots. |
|||
|
|
|||
4 |
The Tv was let to
operate for approx 3 days, and the fault was never formed again. |
|||
|
|
|||
5 |
Voltage on the TDA 8145 in the Seleco TV, and in the Grundig TV |
|||
TDA 8145 |
Grundig |
Seleco |
Pin Function |
|
|
|
|
|
|
Pin 1 |
14.1 V |
14.2 V |
|
|
Pin 2 |
13.4 V |
13.4 V |
|
|
Pin 3 |
8.2 V |
8.3 V |
|
|
Pin 4 |
0 V |
0 V |
Ground |
|
Pin 5 |
9.5 V |
20.2 V |
|
|
Pin 6 |
27.0 V |
27.3 V |
Power Supply |
|
Pin 7 |
9.2 V |
13.3 V |
|
|
Pin 8 |
9.0 V |
13.6 V |
|
|
|
|
|
|
|
|
|
|
|
|
|
Repair summary |
Dry joint in the pin cushion circuitry,
probably the pots area |
Precautions, fouls and advises |
|
|
|
1 |
When a fault is fixed,
leave the TV operating for 2-3 days before handing the TV to the client. |
