Job Number |
|
0204-49 |
|
|
|
|
|
|
||
|
Equipment type |
|
Television |
||
|
|
|
|
||
|
Maker + Model # |
|
Grundig CUC-5360 (ST-65) |
||
|
|
|
|
||
|
Made in |
|
|
|
|
|
|
|
|
||
|
Comments |
|
Already fixed this TV few months ago – completely
different fault. |
||
BAD |
1 |
Shivering, rolling of
picture with presence of ertical lines interference, more severe on warming
up. |
|
|
|
|
|
|
|
|
GOOD |
1 |
On video mode, perfect picture and sound |
|
|
|
|
Full repair description and observations |
|
|
|
|
|
1 |
Since the picture on
playing a video was perfect the suspect imediately fell on the Tuner-IF can |
|
|
|
|
2 |
This was further
confirmed when on spraying freezing spray in the tuner,
the picture came ok for few minutes. |
|
|
|
|
3 |
On opening the tuner to
check its electrolytic capacitors, it was found that all components are
surface mount/nertz type and no further repair could be made |
|
|
|
|
4 |
Other electrolytic
capacitors on the main board which were near the tuner where checked and
found to be ok. |
|
|
|
|
5 |
The tuner was replaced
from Mirald Electronics. The fault was solved, the tuner was faulty. |
|
Repair summary |
TUNER FAULTY |
