My Repair Jobs
|
Job Number |
|
0207-55 |
|
||
|
|
|
|
|||
|
Equipment type |
|
Television 14 inch |
|||
|
|
|
|
|||
|
Maker + Model # |
|
Seleco BS 800 Chassis |
|||
|
|
|
|
|||
|
Made in |
|
|
|
||
|
|
|
|
|||
|
Client Info |
|
George, Odra’s husband |
|||
|
|
|
|
|||
|
Date in |
|
20 July |
2002 |
||
|
Date of repair |
|
27 July |
2002 |
||
|
Date out |
|
30 July |
2002 |
||
|
|
|
|
|||
|
Comments |
|
|
|||
BAD |
1 |
No picture, black raster…, no sound |
|
|
|
|
|
|
2 |
Picture OK on VCR Playback, but no Sound |
|
|
|
|
|
|
3 |
|
|
|
|
|
GOOD |
1 |
Picture OK on VCR Playback, but no sound |
|
|
|
|
|
|
2 |
|
Full repair description and observations |
|
|
|
|
|
1 |
Since the problem is only when the stations
are viewed, but not when viewing, I believed that the tuner needs to be
replaces, while the sound output fault was due something in the sound IC and
circuitry |
|
|
|
|
2 |
When I went to HE Electronics to ask for the
tuner, and explained the symptom, he assured me that the tuner was OK, but
the IC TDA4502a was the fault. |
|
|
|
|
3 |
I replaced the IC (using also a base to make
the work more neet) and the fault was cured |
|
Repair summary |
TDA
4502, IF, Synchro and Deflection control dedicated IC broken. |
