ELECTRONICS CORNER
My Repair Jobs
Job Number |
|
0210-59 |
|
||
|
|
|
|||
Equipment type |
|
Car Stereo Cassette and amplifier |
|||
|
|
|
|||
Maker + Model # |
|
Pioneer KEH-5300 |
|||
|
|
|
|||
Made in |
|
|
|
||
|
|
|
|||
Client Info |
|
Donald’s friend |
|||
|
|
|
|||
Date in |
|
04-Oct |
2002 |
||
Date of repair |
|
05-Oct |
2002 |
||
Date out |
|
10-Oct |
2002 |
||
|
|
|
|||
Comments |
|
|
|||
BAD |
1 |
No sound from bothe channels |
|
|
|
GOOD |
1 |
Powers up and shows good control and tuning |
|
|
|
Full repair description and observations |
|
|
|
1 |
The first suspect fell on
the power amplifer IC, which was a Toshiba TA8215. It showed signs of burn
and so it was obvious. |
|
|
2 |
The IC was replaced and the stereo deck was
assembled. On checking still no sound was present. I was very puzzled?! |
|
|
3 |
I bought another IC in case it needs to be
replaced again. I opened the unit to check the voltages on the IC. |
|
|
4 |
I found out that one pin of the IC was not
soldered, and there was an open track in the mute pin which I casued myself
with the hot sopldering iron while removing the old IC. Fixing these open
tracks, caused the stereo to produce good sound again |
Repair summary |
Power Amplifier IC broken |
Precautions, fouls and advises |
|
|
|
1 |
When replacing an IC
always check that all pins are making continuity with the neighbouring
component/link. This would saved me from wasting time and money (since I
bought another IC) |
1 |
n/a |
